Coal/gas hot blast stove ZDF-QR
Coal/gas hot blast stove ZDF-QR
Product Category:Hot blast stove series
Dual fuel hot blast stove is an innovative product developed by our company according to the production conditions of users. Such as calcium carbide industry drying coke, both can be burned with coal, also flammable with the coke sieve down, can also be burned by electric furnace carbide tail gas; Slag (steel slag) mill supporting boiling furnace, coal or blast furnace gas, fuel can be flexibly switched according to the needs of the automatic control system, mechanical and electrical integrated operation, easy to operate, safe.
Product Introduction

1.Product introduction

Dual fuel hot blast stove is an innovative product developed by our company according to the production conditions of users. Such as calcium carbide industry drying coke, both can be burned with coal, also flammable with the coke sieve down, can also be burned by electric furnace carbide tail gas; Slag (steel slag) mill supporting boiling furnace, coal or blast furnace gas, fuel can be flexibly switched according to the needs of the automatic control system, mechanical and electrical integrated operation, easy to operate, safe.

2.Main performance and characteristics

(1)With fluidized bed combustion technology, it has wide fuel adaptability, high thermal efficiency and stable heating temperature.
(2)Two sets of combustion devices share a furnace, can be used alone, or can be used at the same time;
(3)A cooling channel is designed to effectively protect another set of combustion units when using a single fuel;
(4)Adopt centralized thermal control system, combustion monitoring system, centralized display, automatic control;
(5)Automatic ignition, pressure protection, flameout protection, with sound and light alarm, network control and other features.

Product parameter introduction

Model Heating capacitykJ/h Hot air temperature ℃ Coal consumptionkg/h Air consumption Nm³/h Installed power kW
ZDF-QR2 2×4.18×10° 500~800 297 245 13
ZDF-QR4 4×4.18×10? 500~800 594 490 30
ZDF-QR6 6×4.18×10? 500~800 891 735 40.5
ZDF-QR8 8×4.18×10° 500~800 1188 980 48.5
ZDF-QR10 10×4.18×10? 500~800 1485 1225 55.5
ZDF-QR12 12×4.18×10? 500~800 1782 1470 63.5
ZDF-QR16 16×4.18×10? 500~800 2376 1960 77
ZDF-QR20 20×4.18×10? 500~800 2970 2450 97



Note: Energy consumption in the table refers to the state of single combustion of fuel, natural gas, and calorific value is 8500kcal/Nm3

Instructions for ordering


Installation precautions
